Blackmagic Design 6G HDMI to SDI Mini Converter

Technical Details

Blackmagic Design Mini Converter - HDMI to SDI 6G The Blackmagic Design HDMI to SDI 6G Mini Converter effortlessly transitions HDMI signals to SD, HD, 3G, or 6G-SDI, accommodating resolutions as high as DCI 4K (4096 x 2160 at 24p) and UHD 4K (3840 x 2160 up to 30p).

This compact, yet powerful converter is the perfect solution for marrying consumer HDMI devices with professional SDI equipment within broadcast, post-production, and AV settings. It intuitively recognises input formats and toggles between SD, HD, and 4K resolutions, while its dual 6G-SDI outputs offer duplicate signals for adaptable workflow integration.

Audio can be embedded from the HDMI input or through two 1/4" jacks that support four channels of AES/EBU digital or two channels of analogue audio.

Key Features

• Transitions HDMI signals to SD, HD, 3G, or 6G-SDI
• Accommodates resolutions as high as DCI 4K and UHD 4K
• Intuitively recognises input formats and toggles between SD, HD, and 4K resolutions
• Dual 6G-SDI outputs offer duplicate signals
• Audio can be embedded from the HDMI input or through two 1/4" jacks

The Mini Converter features 4:2:2 sampling, an HD scaler, SD down-conversion, and 24-bit/48 kHz audio sampling, ensuring high-quality signal processing. It complies with SMPTE and ITU-R standards, including SMPTE 259M/292M/296M/372M/424M/425M and ITU-R BT.656/BT.601.

Settings can be adjusted via built-in switches or USB using Blackmagic Design's control software for macOS and Windows, which also enables firmware updates. The device is powered by an included 12V supply with international socket adaptors, making it versatile for global use.
