Blackmagic Design SDI-to-Analog 12G Teranex Mini
Our price $835.00
Please fill in the details below and we will be in touch shortly.
Blackmagic Design SDI-to-Analog 12G Teranex Mini
Blackmagic Design SDI-to-Analog 12G Teranex Mini is backordered and will ship as soon as it is back in stock.
At a glance
The Blackmagic Design Teranex Mini - SDI to Analog 12G is an accessory from Blackmagic Design.
Description
Description
Key Features
- Handles up to 12G-SDI data rates
- Equipped with full-size XLR outputs
- Smart thermal design with crossflow cooling
- Integrated 90-240V power supply
Conversion
The converter takes SD, HD and Ultra HD SDI and converts it to YUV, S-Video or composite, with analog or AES/EBU audio. 12G-SDI supports Ultra HD up to 2160p60 on a single BNC cable.
Audio and power
Full-size XLR outputs can be switched between balanced analog and AES/EBU digital audio. A built-in multi volt 90V-240V AC power supply uses a standard IEC AC power connector.
Control and cooling
Ethernet is used for remote administration. The converter can also be powered over ethernet when connected to a power over ethernet switch. Its thermal design uses crossflow cooling with an internal heat pipe. An optional Smart Panel adds an LCD, push buttons and on-screen menus. The unit can be rack mounted alone or in groups, or used on a desktop.
Software
The included Converter Utility software runs on Mac or Windows.
Why choose it
- Converts SD, HD and Ultra HD SDI to YUV, S-Video or composite
- Full-size XLR outputs for balanced analog or AES/EBU audio
- Converter Utility software for Mac or Windows
- Can be powered over ethernet
